Product Name : 512C-32-00-00-00
Old Code : 512C/32/00/00/00
Phase : Single Phase (230V)
Supply Voltage : 110-480V
Current Rating : 16A
Auxiliary Supply : Switchable 115/230VAC
Directions



Part No: 512C-32-00-00-00 (512C/32/00/00/00)
Phase : Single Phase (230V)
Supply Voltage : 110-480V
Current Rating : 32.0A
Quadrant : Single Quadrant (Non-Regenerative)
Auxiliary Supply : Switchable 115/230VAC
Description:
Isolated control circuitry, a host of user facilities and extremely linear control loop make the 512C ideal for single
motor or multi-drive low power applications. Designed for use on single phase supplies, the 512C is suitable for
controlling permanent magnet or field wound DC motors in speed or torque control.
Switch selectable supply power:
Single Phase 110Vac ±10%
Single Phase 220Vac ±10%
Single Phase 380Vac ±10%
Single Phase 480Vac ±10%
50-60Hz ±5%
Ambient:
Temperature : 0-40°C
150% for 60 seconds
 Motor protection:
Stall condition 15 seconds internal
Electronic Overload Protection
Available frame sizes:
4, 8, 16 and 32 ampere


Available frame sizes:
4, 8, 16 and 32 ampere
View of Components Parts:

Stock & Application

Control Board
