Product Name : 590C/1100/6/1/0/0/0/00 591C/1100/6/1/0/0/0/00/000
Manufacturers Series : Parker SSD 590C/591C
Current Extra : 4Q (Regen) 2Q (Non-regen)
Current : 110A
Supply Input : 220-500Vac 3PH
Output : 460Va
Directions

blob.png       blob.png

590 manufacturer is Parker Hannifin SSD Drives Division, previously known as SSD Drives, Eurotherm Drives and Shackleton System Drives.
590 manufacturer is Parker Hannifin SSD Drives Division, previously known as SSD Drives, Eurotherm Drives and Shackleton System Drives.
Part No:
 590C/1100/6/1/0/0/0/00   591C/1100/6/1/0/0/0/00/000
Description:

The 590 Series Converter is designed for use in a suitable enclosure, with associated control equipment. The unit accepts standard three-phase ac supply voltages in the range 110V to 660V, depending upon the model, and is suitable for the powering of DC shunt field and permanent magnet motors, providing controlled dc output voltage and current for armature and field.

Mains Supply: 3-phase, 50/60Hz, earth referenced (TN) and non-earth referenced (IT).

Operating Supply Tolerance: ±10%

Voltage Ranges: 220 to 500V AC

Supply Current: (0.9 x Idc) Amps ac rms

Field Supply:  500V maximum Phase 3-phase rotation insensitive

Motor Power @ 460V DC: 45kW (110A)

Parker SSD Line Choke Part Number:  CO463038 (110)

Parker SSD External Fuses Part Number:  CH110353 (110A)


View of Component Parts:
