Part No: 6901-00-B (6901/00/B)
Description:
Eurotherm Drives or SSD Drives 6901-00-B Keypad/Operator Station & Alpha Numeric Display. The "B" in the product code stands for the colour "Blue" which indicates that the keypad would have been manufactured during the same period that the Eurotherm drives were a teal blue colour. The drives are now manufactured by Parker SSD Drives and are now Grey but the keypad is now 6901-00-G - "G" Stands for "Gold".
The Blue 6901-00-B keypad was used with all of the following Drives (When they were blue):-
- AC 690+ (or 690P)
- AC 890SD & 890CD (Factory fitted on 37kW and up but compatible with lower sizes)
- DC 590+ (or 590P)
- DC 591+ (or 591P)
- DC 590+DRV (or 590P-DRV)
- DC 591+DRV (or 591P-DRV)
- Older style "Grey" 590C Drives (When using 590PXD Door - this also used to be blue)
- AC 605 Drives (Frames A, B & C)
- AC 650 / 650V (Can be fitted to all sizes of 650/650V when 'DISPR'- or 'A2' appears in the part number)
- AC 584SV (Can be used to replace the old 5841 keypad)
It provides Local control of the drive, monitoring and complete access for application programming.
For example, you can start and stop the motor, check on diagnostic information, and change parameters value
