Electrical data

Ratings per IEC/EN

Ratings per IEC/EN 60947-7-1

Nominal voltage (III/3) 800V

Rated impulse voltage (III/3) 8kV

Rated current 13.5A

Legend (ratings) (III / 3) ≙ Overvoltage category III / Pollution degree 3

Ratings per IEC/EN 2

Rated current 2 17.5A

Ratings per UL

Approvals per UL 1059

Rated voltage UL (Use Group B) 600V

Rated current UL (Use Group B) 15A

Rated voltage UL (Use Group C) 600V

Rated current UL (Use Group C) 15A

Ratings per CSA

Approvals per CSA 22.2 No 158

Rated voltage CSA (Use Group B) 600V

Rated current CSA (Use Group B) 10A

Rated voltage CSA (Use Group C) 600V

Rated current CSA (Use Group C) 10A

Ex information

Reference hazardous areas See Downloads – Documentation – Additional Information: Technical Section; Technical explanations

Ratings per ATEX: PTB 11 ATEX 1041 U / IECEx: PTB 11.0093U (Ex eb IIC Gb)

Rated voltage EN (Ex e II) 550V

Rated current (Ex e II) 13A

Rated current (Ex e II) with jumper 12A

Power loss

Power loss, per pole (potential) 0.434W

Rated current IN for specified power loss 13.5A

Resistance value for specified, current-dependent power loss 0.002Ω
