Ratings per IEC/EN
Ratings per IEC/EN 60947-7-1
Nominal voltage (III/3) 800V
Rated surge voltage (III/3) 8kV
Rated current 24A
Rated current 2 32A
More
Ratings per UL
Approvals per UL 1059
Rated voltage UL (Use Group B) 600V
Rated current UL (Use Group B) 20A
Rated voltage UL (Use Group C) 600V
Rated current UL (Use Group C) 20A
Ratings per CSA
Approvals per C22.2 No 158
Rated voltage CSA (Use Group B) 600V
Rated current CSA (Use Group B) 20A
Rated voltage CSA (Use Group C) 600V
Rated current CSA (Use Group C) 20A
Ex information
Ratings per ATEX: PTB 03 ATEX 1162 U / IECEx: PTB 03.0004U (Ex eb IIC Gb)
Rated voltage EN (Ex e II) 550V
Rated current (Ex e II) 22A
Rated current (Ex e II) with jumper 20A
Ratings (note) See installation notes in section “Knowledge” and
Downloads – Documentation – Additional Information: Technical explanations
Connection data
Total number of connection points 2
Total number of potentials 1
Number of levels 1
Number of jumper slots 2
Connection 1
Connection technology Push-in CAGE CLAMP®
Actuation type Push-in
Operating tool
Connectable conductor materials Copper
Nominal cross-section 2.5 mm²
Solid conductor 0.25 … 4 mm² / 22 … 12 AWG
