Electrical data
Ratings per IEC/EN
Ratings per IEC/EN 60947-7-1
Nominal voltage (III/3) 400V
Rated surge voltage (III/3) 6kV
Rated current 16A
Legend (ratings) (III / 3) ≙ Overvoltage category III / Pollution degree 3
Ratings per UL
Approvals per UL 1059
Rated voltage UL (Use Group B) 300V
Rated current UL (Use Group B) 15A
Rated voltage UL (Use Group C) 300V
Rated current UL (Use Group C) 15A
Ratings per CSA
Approvals per C22.2 No 158
Rated voltage CSA (Use Group B) 300V
Rated current CSA (Use Group B) 15A
Rated voltage CSA (Use Group C) 300V
Rated current CSA (Use Group C) 15A
Ex information
Ratings per ATEX: KIWA 17 ATEX 0030 U / IECEx: KIWA 17.0014U (Ex ec IIC Gc)
Rated voltage EN (Ex e II) 440V
Rated current (Ex e II) 17A
Ratings (note) See Downloads – Documentation – Additional Information: Technical explanations
Connection data
Total number of connection points 2
Total number of potentials 2
Number of levels 1
Number of jumper slots 2
Connection 1
Connection technology Push-in CAGE CLAMP®
Actuation type Push-in
Operating tool
Connectable conductor materials Copper
Nominal cross-section 2.5 mm²
Solid conductor 0.25 … 4 mm² / 22 … 12 AWG
