Electrical data

Voltage type 1 AC/DC

Power loss (max.) Pl (max.) (note) When selecting glass cartridge fuses, make sure that the maximum power loss listed below is not exceeded. The power loss is determined according to IEC or EN 60947-7-3/VDE 0611-6 at 23°C. The temperature rise of the terminal block must be checked according to their application and mounting. Higher ambient temperatures represent an additional impact on miniature fuses. Therefore, in such applications, the rated current must be reduced if necessary. More details are available from the manufacturers.

Power loss Pl (max.) 2.5W

Power loss Pl (note) Overload and short circuit protection (Individual arrangement)

Power loss Pl 2 (max.) 1.6W

More

IEC Approvals

Ratings (note) Electrical ratings are given by the fuse and blown fuse indication.

Rated voltage (III / 3) 250V

Rated current 6.3A

Note on rated current 1 Leakage current in case of a blown fuse: LED 5 … 20 mA

Operation status indicator without

Physical data

Width 6 mm / 0.236 inch

Mechanical data

Marking level Center marking

Art der Sicherung Cylindrical fuse 5 x 20 mm and cylindrical fuse 5 x 25 mm

Material data

Color gray

Insulation material Polyamide (PA66)

Fire load 0.081MJ

Weight 6.7g

Commercial data

Product Group 1 (Rail Mounted Terminal Blocks)

PU (SPU) 50 Stück

Packaging type box

Country of origin CN

GTIN 4050821276265
