Ratings per IEC/EN 60664-1

Ratings per IEC/EN 60947-7-3

Nominal voltage (III/3) 800V

Rated surge voltage (III/3) 8 kV

Rated current 10A

Operation status indicator 120 V

Legend (ratings) (III / 3) ≙ Overvoltage category III / Pollution degree 3

Connection data

Connection technology CAGE CLAMP®

Actuation type Operating tool

Connectable conductor materials Copper

Aluminum

Solid conductor 0,08 … 4 mm² / 28 … 12 AWG

Fine-stranded conductor 0,08 … 4 mm² / 28 … 12 AWG

Strip length 9 … 10 mm / 0.35 … 0.39 inch

Total number of connection points 2

Total number of potentials 2

Number of levels 1

Wiring type Front-entry wiring

Geometrical Data

Width 8 mm / 0.315 inch

Height from upper-edge of DIN-rail 60 mm / 2.362 inch

Depth 60 mm / 2.362 inch

Mechanical data

Design angled

Mounting type DIN-35 rail

Marking level Center marking
