Ratings per IEC/EN
Ratings per IEC/EN 60947-7-1
Nominal voltage (III/3) 800V
Rated surge voltage (III/3) 8kV
Rated current 57A
Legend (ratings) (III / 3) ≙ Overvoltage category III / Pollution degree 3
Connection data
Total number of connection points 2
Total number of potentials 1
Number of levels 1
Connection 1
Connection technology CAGE CLAMP®
Actuation type Operating tool
Connectable conductor materials Copper
Solid conductor 0.2 … 10 mm² / 24 … 8 AWG
Fine-stranded conductor 0.2 … 10 mm² / 24 … 8 AWG
Physical data
Width 10 mm / 0.394 inch
Height 69 mm / 2.717 inch
Depth from upper edge of DIN-rail 33.5 mm / 1.319 inch
Mechanical data
Design horizontal type
Mounting type DIN-35 rail
Marking level Side marking
