Electrical data

Ratings per IEC/EN

Nominal voltage (III/3) 800V

Rated impulse voltage (III/3) 8kV

Rated current 125A

Legend (ratings) (III / 3) ≙ Overvoltage category III / Pollution degree 3

Power loss

Power loss, per pole (potential) 8.75W

Rated current IN for specified power loss 125A

Resistance value for specified, current-dependent power loss 0.001Ω

Connection data

Total number of connection points 4

Total number of potentials 1

Number of levels 1

Connection 1

Connection technology CAGE CLAMP®

Number of connection points 3

Actuation type Operating tool

Connectable conductor materials Copper

Solid conductor 0.2 … 10 mm² / 24 … 8 AWG

Fine-stranded conductor 0.2 … 10 mm² / 24 … 8 AWG

Strip length 12 … 14 mm / 0.47 … 0.55 inches

Wiring direction Front-/side-entry wiring

Connection 2

Connection technology 2 Screw connection

Number of connection points 2 1

Solid conductor 2 0.5 … 35 mm² / 10 … 2 AWG

Fine-stranded conductor 2 6 … 35 mm² / 10 … 2 AWG
