Details
Electrical data
Ratings per IEC/EN
Ratings per IEC/EN 60947-7-2
Connection data
Total number of connection points 4
Total number of potentials 1
Number of levels 1
Number of jumper slots 2
Connection 1
Connection technology Push-in CAGE CLAMP®
Actuation type Push-in
Operating tool
Connectable conductor materials Copper
Nominal cross-section 1.5 mm²
Solid conductor 0.25 … 2.5 mm² / 22 … 14 AWG
More
Physical data
Width 4.2 mm / 0.165 inch
Height 69.9 mm / 2.752 inch
Depth from upper edge of DIN-rail 32.9 mm / 1.295 inch
Mechanical data
Design horizontal type
Mounting type DIN-35 rail
Marking level Center/side marking
Material data
Color green-yellow
Insulation material Polyamide (PA66)
Flammability class per UL94 V0
Weight 8.7g
Commercial data
Product Group 22 (TOPJOB S)
PU (SPU) 100 Stück
Packaging type box
Country of origin DE
GTIN 4055143616973
