Electrical data
Ratings per IEC/EN
Nominal voltage (III/3) 250V
Rated impulse voltage (III/3) 4kV
Rated voltage (III/2) 500V
Rated impulse voltage (III/2) 4kV
Rated current 32A
More
Connection data
Total number of potentials 8
Number of levels 1
Preceding contacts 0
Connection 1
Pole number 8
Physical data
Pin spacing 5 mm / 0.197 inch
Width 54.7 mm / 2.154 inch
Height from the surface 18.3 mm / 0.72 inch
Depth 22.2 mm / 0.874 inch
Mechanical data
Variable coding Yes
Mounting type Feedthrough flange
Plug-in connection
Contact type (pluggable connector) Male connector/plug
Connector (connection type) for PCB
Mismating protection No
Mating direction to the PCB 0°
PCB contact
PCB Contact THT
Material data
Note (material data) Information on material data can be found here
Color gray
Insulation material Polyamide (PA66)
Flammability class per UL94 V0
Fire load 0.211MJ
