Ratings per IEC/EN

Ratings per IEC/EN 60947-7-1

Nominal voltage (III/3) 800V

Rated surge voltage (III/3) 8kV

Rated current 32A

Rated current 2 41A

Ratings per UL

Approvals per UL 1059

Rated voltage UL (Use Group B) 600V

Rated current UL (Use Group B) 30A

Rated voltage UL (Use Group C) 600V

Rated current UL (Use Group C) 30A

Ratings per CSA

Approvals per C22.2 No 158

Rated voltage CSA (Use Group B) 600V

Rated current CSA (Use Group B) 30A

Rated voltage CSA (Use Group C) 600V

Rated current CSA (Use Group C) 30A

Ex information

Ratings per ATEX: PTB 05 ATEX 1095 U / IECEx: PTB 05.0033U (Ex eb IIC Gb)

Rated voltage EN (Ex e II) 550V

Rated current (Ex e II) 30A

Ratings (note) See installation notes in section “Knowledge” and

Downloads – Documentation – Additional Information: Technical explanations

Connection data

Total number of connection points 2

Total number of potentials 1

Number of levels 1

Number of jumper slots 2

Connection 1

Connection technology Push-in CAGE CLAMP

Actuation type Push-in

Operating tool

Connectable conductor materials Copper

Nominal cross-section 4 mm²

Solid conductor 0.5 … 6 mm² / 20 … 10 AWG
