Details

Electrical data

Ratings per IEC/EN

Ratings per IEC/EN 60947-7-2

Connection data

Total number of connection points 3

Total number of potentials 1

Number of levels 1

Connection 1

Connection technology CAGE CLAMP®

Actuation type Operating tool

Connectable conductor materials Copper

Solid conductor 0.08 … 1.5 mm² / 28 … 16 AWG

Fine-stranded conductor 0.08 … 1.5 mm² / 28 … 16 AWG

More

Physical data

Width 4 mm / 0.157 inch

Height 62.5 mm / 2.461 inch

Depth from upper edge of DIN-rail 27 mm / 1.063 inch

Mechanical data

Design horizontal type

Mounting type DIN-35 rail

Marking level Center marking

Material data

Color green-yellow

Insulation material Polyamide (PA66)

Flammability class per UL94 V0

Fire load 0.088MJ

Weight 8.9g

Commercial data

PU (SPU) 100 Stück

Packaging type box

Country of origin DE

GTIN 4045454084448

Customs tariff number 85369010000
