Features:
- Self-correction
- Large screen LED display
- Heating / cooling control
- Temperature alarm
- Heater break alarm
- The first alarm table {ALM1} (the standard built-in):
- A: maximum deviation alarm
- B: lower limit deviation alarm
- C: upper and lower limit deviation alarm
- D: within the police
- E: maximum deviation alarm with standby
- F: lower limit deviation alarm with standby
- G: upper and lower limit deviation alarm with standby
- H: limit input value alarm
- J: limit input value alarm
- K: limit input value alarm with standby
- L: lower limit input value alarm with standby
Control output :
- Logic voltage DC 0/5V
- Hole Size: 45 +1 X 92 +1 mm
- Power Supply: AC85-264V 50/60Hz
- Input: K type Thermocouple(0-400C)
- Relay contact AC250V 3A (resistance)
- Zero trigger pulse: optical dual SCR output 1A 600V
- Phase trigger pulse: optical dual SCR output 1A 600V
- Transmission output: 0-10mA ,4-20mA, 0-5V, 1-5V
- Power output: DC24V (used for two-wire transmitter)
- Dimensions:48 x 96 x100mm (Width x high x depth)
- 0-10mA ,0-20mA ,4-20mA current output (load resistance 600Ω or less)
- Alarm type :Upper limit alarm, lower limit alarm
