Siemens Motor Starter Contactors - Series 3TF2
3TF2 3-Pole with AC Coil
Frame | Amp | Three phase | Auxiliary | Catalog No | |||||
Size | Ratings | HP Ratings | Contacts | ||||||
UL/CSA | AC3 | AC1 | 230V | 460V | NO | NC | Screw Terminals | Spring Terminals | |
S00 | 16 | 9 | 22 | 3 | 5 | 3TF20 | |||
1 | 0 | 3TF2010-0A | 3TF2010-1A | ||||||
0 | 1 | 3TF2001-0A | 3TF2001-1A | ||||||
S00 | 16 | 9 | 22 | 3 | 5 | 3TF21 | |||
1 | 1 | 3TF2111-0A | 3TF2111-1A | ||||||
2 | 2 | 3TF2122-0A | 3TF2122-1A | ||||||
S00 | 16 | 9 | 22 | 3 | 5 | 3TF22 | |||
1 | 1 | 3TF2211-0A | 3TF2211-1A | ||||||
2 | 2 | 3TF2222-0A | 3TF2222-1A | ||||||
S00 | - | 7 | 18 | 2 | 3 | 3TF28 | |||
1 | 0 | 3TF2810-0A | 3TF2810-1A | ||||||
3TF20 4-Pole with AC Coil
Frame | Amp | Three phase | Auxiliary | Catalog No | |||||
Size | Ratings | HP Ratings | Contacts | ||||||
UL/CSA | AC3 | AC1 | 230V | 460V | NO | NC | Screw terminals | Spring terminals | |
S00 | 16 | 9 | 22 | 3 | 5 | 3TF2080 | |||
0 | 0 | 3TF2080-0A | 3TF2080-1A | ||||||
0 | 0 | 3TF2082-0A | 3TF2082-1A | ||||||
3TF2 3-Pole with DC Coil
Frame | Amp | Three phase | Auxiliary | Catalog No | |||||
Size | Ratings | HP ratings | Contacts | ||||||
UL/CSA | AC3 | AC1 | 230V | 460V | NO | NC | Screw Terminals | Spring Terminals | |
S00 | 16 | 9 | 22 | 3 | 5 | 3TF20 | |||
1 | 0 | 3TF2010-0B | 3TF2010-1B | ||||||
0 | 1 | 3TF2001-0B | 3TF2001-1B | ||||||
S00 | 16 | 9 | 22 | 3 | 5 | 3TF21 | |||
1 | 1 | 3TF2111-0B | 3TF2111-1B | ||||||
2 | 2 | 3TF2122-0B | 3TF2122-1B | ||||||
S00 | 16 | 9 | 22 | 3 | 5 | 3TF22 | |||
1 | 1 | 3TF2211-0B | 3TF2211-1B | ||||||
2 | 2 | 3TF2222-0B | 3TF2222-1B | ||||||
S00 | - | 7 | 18 | 2 | 3 | 3TF28 | |||
1 | 0 | 3TF2810-0B | 3TF2810-1B | ||||||
0 | 1 | 3TF2801-0B | 3TF2801-1B | ||||||
S00 | - | 7 | 18 | 2 | 3 | 3TF29 | |||
1 | 1 | 3TF2911-0B | 3TF2911-1B | ||||||
2 | 2 | 3TF2922-0B | 3TF2922-1B | ||||||
3TF2 3-Pole with DC Coil3TF2 3-Pole with DC Coil: Incorporated Surge Suppressor
Frame | Amp | Three phase | Auxiliary | Catalog No | |||||
Size | Ratings | HP Ratings | Contacts | ||||||
UL/CSA | AC3 | AC1 | 230V | 460V | NO | NC | Screw Terminals | Spring Terminals | |
S00 | 16 | 9 | 22 | 3 | 5 | 3TF20 | |||
1 | 0 | 3TF2010-0LB4 | - | ||||||
0 | 1 | 3TF2001-0LB4 | - | ||||||
1 | 0 | 3TF2010-0DB4 | - | ||||||
0 | 1 | 3TF2001-0DB4 | - | ||||||
1 | 0 | 3TF2010-0JB4 | - | ||||||
0 | 1 | 3TF2001-0JB4 | - | ||||||
1 | 0 | 3TF2010-0FB4 | - | ||||||
0 | 1 | 3TF2001-0FB4 | - | ||||||
1 | 0 | 3TF2010-0TB4 | - | ||||||
0 | 1 | 3TF2001-0TB4 | - | ||||||
1 | 0 | 3TF2010-0MB4 | - | ||||||
0 | 1 | 3TF2001-0MB4 | - | ||||||
S00 | - | 7 | 18 | 2 | 3 | 3TF28 | |||
1 | 0 | 3TF2810-0LB4 | - | ||||||
0 | 1 | 3TF2801-0LB4 | - | ||||||
1 | 0 | 3TF2810-0DB4 | - | ||||||
0 | 1 | 3TF2801-0DB4 | - | ||||||
1 | 0 | 3TF2810-0JB4 | - | ||||||
0 | 1 | 3TF2801-0JB4 | - | ||||||
1 | 0 | 3TF2810-0FB4 | - | ||||||
0 | 1 | 3TF2801-0FB4 | - | ||||||
1 | 0 | 3TF2810-0TB4 | - | ||||||
0 | 1 | 3TF2801-0TB4 | - | ||||||
1 | 0 | 3TF2810-0MB4 | - | ||||||
0 | 1 | 3TF2801-0MB4 | - | ||||||
