Ratings per IEC/EN
Ratings perIEC/EN 60947-7-1
Nominal voltage (III/3)500V
Rated surge voltage (III/3)6kV
Rated current13.5A
Rated current 216A
More
Ratings per UL
Approvals perUL 1059
Rated voltage UL (Use Group B)300V
Rated current UL (Use Group B)15A
Rated voltage UL (Use Group C)300V
Rated current UL (Use Group C)15A
Ratings per CSA
Approvals perC22.2 No 158
Rated voltage CSA (Use Group B)600V
Rated current CSA (Use Group B)10A
Rated voltage CSA (Use Group C)600V
Rated current CSA (Use Group C)10A
Ex information
Ratings perATEX: PTB 11 ATEX 1041 U / IECEx: PTB 11.0093U (Ex eb IIC Gb)
Rated voltage EN (Ex e II)350V
Rated current (Ex e II)13A
Rated current (Ex e II) with jumper12A
Ratings (note)See Downloads – Documentation – Additional Information: Technical explanations
Connection data
Total number of connection points4
Total number of potentials1
Number of levels2
Number of jumper slots3
Connection 1
Connection technologyPush-in CAGE CLAMP®
Actuation typePush-in
Operating tool
Connectable conductor materialsCopper
Nominal cross-section1 mm²
Solid conductor0.14 … 1.5 mm² / 24 … 16 AWG
