Ratings per IEC/EN
Ratings per IEC/EN 60947-7-1
Nominal voltage (III/3) 800V
Rated surge voltage (III/3) 8kV
Rated current 32A
Rated current 2 41A
More
Ratings per UL
Approvals per UL 1059
Rated voltage UL (Use Group B) 600V
Rated current UL (Use Group B) 30A
Rated voltage UL (Use Group C) 600V
Rated current UL (Use Group C) 30A
Ratings per CSA
Approvals per C22.2 No 158
Rated voltage CSA (Use Group B) 600V
Rated current CSA (Use Group B) 30A
Rated voltage CSA (Use Group C) 600V
Rated current CSA (Use Group C) 30A
Ex information
Ratings per ATEX: PTB 05 ATEX 1095 U / IECEx: PTB 05.0033U (Ex eb IIC Gb)
Rated voltage EN (Ex e II) 550V
Rated current (Ex e II) 30A
Ratings (note) See installation notes in section “Knowledge” and
Downloads – Documentation – Additional Information: Technical explanations
