Electrical data
Verlustleistung, pro Pol (Potential) 2.029W
Bemessungsstrom IN zur Verlustleistungsangabe 51A
Widerstandswert zur stromabhängigen Verlustleistungsangabe 0.001Ω
Ratings per IEC/EN
Nominal voltage (III/3) 250V
Rated impulse voltage (III/3) 4kV
Rated current 51A
Legend (ratings) (III / 3) ≙ Overvoltage category III / Pollution degree 3
Connection data
Total number of connection points 1
Total number of potentials 1
Number of levels 1
Number of jumper slots 2
Connection 1
Connection technology Push-in CAGE CLAMP®
Actuation type Push-in
Operating tool
Connectable conductor materials Copper
Nominal cross-section 6 mm²
Solid conductor 0.5 … 10 mm² / 20 … 8 AWG
Solid conductor; push-in termination 2.5 … 10 mm² / 14 … 8 AWG
Fine-stranded conductor 0.5 … 10 mm² / 20 … 8 AWG
Fine-stranded conductor; with insulated ferrule 0.5 … 6 mm² / 20 … 10 AWG
Fine-stranded conductor; with ferrule; push-in termination 2.5 … 6 mm² / 16 … 10 AWG
Note (conductor cross-section) Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination.
Strip length 13 … 15 mm / 0.51 … 0.59 inches
Wiring direction Front-entry wiring
