WAGO 284-904 2-conductor through terminal block; 10 mm²; center marking; for DIN-rail 35 x 15 and 35 x 7.5; CAGE CLAMP; 10,00 mm²; blue

WAGO 3-conductor ground terminal block; 1.5 mm²; center marking; for DIN-rail 35 x 15 and 35 x 7.5; CAGE CLAMP; 1,50 mm²; green-yellow 279-687

Product Name : WAGO 284-904 2-conductor through terminal block; 10 mm²; center marking; for DIN-rail 35 x 15 and 35 x 7.5; CAGE CLAMP; 10,00 mm²; blue

Directions

Ratings per IEC/EN

Ratings per IEC/EN 60947-7-1

Nominal voltage (III/3) 800V

Rated surge voltage (III/3) 8kV

Rated current 57A

Legend (ratings) (III / 3) ≙ Overvoltage category III / Pollution degree 3

Connection data

Total number of connection points 2

Total number of potentials 1

Number of levels 1

Connection 1

Connection technology CAGE CLAMP®

Actuation type Operating tool

Connectable conductor materials Copper

Solid conductor 0.2 … 10 mm² / 24 … 8 AWG

Fine-stranded conductor 0.2 … 10 mm² / 24 … 8 AWG

Physical data

Width 10 mm / 0.394 inch

Height 78 mm / 3.071 inch

Depth from upper edge of DIN-rail 35 mm / 1.378 inch

Mechanical data

Design horizontal type

Mounting type DIN-35 rail

Marking level Center marking
