WAGO 769-610 X-COM 1-conductor male connector; 4 mm²; Pin spacing 5 mm; 10-pole; 4,00 mm²; gray

WAGO 3-conductor ground terminal block; 1.5 mm²; center marking; for DIN-rail 35 x 15 and 35 x 7.5; CAGE CLAMP; 1,50 mm²; green-yellow 279-687

Product Name : WAGO 769-610 X-COM 1-conductor male connector; 4 mm²; Pin spacing 5 mm; 10-pole; 4,00 mm²; gray

Directions

Ratings per IEC/EN

Nominal voltage (III/3)500V

Rated surge voltage (III/3)6kV

Rated current32A

Legend (ratings)(III / 3) ≙ Overvoltage category III / Pollution degree 3

Connection data

Total number of connection points10

Total number of potentials10

Connection 1

Connection technologyCAGE CLAMP®

Actuation typeOperating tool

Connectable conductor materialsCopper

Nominal cross-section4 mm²

Solid conductor0.08 … 4 mm² / 28 … 12 AWG

Physical data

Pin spacing5 mm / 0.197 inch

Width53.6 mm / 2.11 inch

Height18.3 mm / 0.72 inch

Depth40.2 mm / 1.583 inch

Mechanical data

Variable codingJa

Mounting typeFlying leads

Plug-in connection

Contact type (pluggable connector)Male connector/plug

Connector (connection type)for conductor
