The West 8100+ is part of the Plus Series of controllers that take flexibility and ease of use to new levels.
The 8100+ controller is an evolved product from the N8100. The product benefits from having more versatile features and user-friendly functionalities such as remote setpoint inputs, digital inputs, plug-in output modules, a customisable operator/HMI menu, jumperless and auto-hardware configuration, and 24VDC transmitter power supply.
It has been designed to incorporate improvements, save users’ time (as much as 50% on product set-up), reduce inventory stock and virtually eliminate the likelihood of operator errors.
ManufacturerWest Control Solutions
SeriesWest 8100+
Din Size1/8
Dimensions and Size96mm x 48mm x 100mm (HxWxD), 1/8 DIN
Primary Input TypeUniversal (TC, RTD, DC linear mA/mV)
Other InputsDigital, Remote setpoint
Output TypeRelay, SSd, DC linear V or mA, Triac, 24V transmitter power supply
Max. Number of Outputs 3
Control TypePID, ON/OFF, Manual, Alarm, Ramp to Setpoint
Power Supply100–240V AC 50–60Hz
20-48V AC 50/60 Hz 22-65V DC
CommunicationsRS-485 serial (West ASCII or MODBUS®)
Panel SealingIEC IP66 (Behind panel protection is IP20), NEMA4X
CertificationsCE, UL, ULC, CSA
Software ToolsPlus Series Configurator
