Part No: 31V-4G0045-BE-2S-0000
Phase : Three Phase (415V)
Supply Voltage : 400-480V
Power Rating : 22.0KW
Current Rating : 45.0A
Frame Size : Frame G
PCB Coating : Standard 3C3 Coating
Filter : Cat C3 (Industrial) EMC Filter
Keypad : Fitted
Description:
45A / 22kW Normal Duty Rating - Frame Size 'G'
AC30V drive has been designed to provide users with exceptional levels of control for pump, fan and general purpose applications. Its flexible and highly modular construction enables a wide range of communications and I/O modules to be easily added as required.
Rated Input Voltage: 3Ø 380...480VAC ±10%
Input Frequency: 45...65 Hz
Maximum Switching Frequency: 4 kHz up to maximum of 12 kHz
Overload: Heavy Duty: 150 % for 30 seconds - 180% for 0.5 seconds
Overload: Normal Duty: 110 % for 30 seconds - 180% of HD FLC. for 0.5 seconds
control wiring connections
Dimensions -- Panel Mounting
Dimensions -- Through Panel Mounting
Technical Characteristic
Applications
