Ratings per IEC/EN
Ratings per IEC/EN 60947-7-1
Nominal voltage (III/3) 800V
Rated surge voltage (III/3) 8kV
Rated current 13.5A
Rated current 2 17.5A
More
Ratings per UL
Approvals per UL 1059
Rated voltage UL (Use Group B) 600V
Rated current UL (Use Group B) 15A
Rated voltage UL (Use Group C) 600V
Rated current UL (Use Group C) 15A
Ratings per CSA
Approvals per C22.2 No 158
Rated voltage CSA (Use Group B) 600V
Rated current CSA (Use Group B) 10A
Rated voltage CSA (Use Group C) 600V
Rated current CSA (Use Group C) 10A
Ex information
Ratings per ATEX: PTB 11 ATEX 1041 U / IECEx: PTB 11.0093U (Ex eb IIC Gb)
Rated voltage EN (Ex e II) 550V
Rated current (Ex e II) 13A
Rated current (Ex e II) with jumper 12A
Ratings (note) See Downloads – Documentation – Additional Information: Technical explanations
