Ratings per IEC/EN

Ratings per IEC/EN 60947-7-1

Nominal voltage (III/3) 800V

Rated surge voltage (III/3) 8kV

Rated current 57A

Legend (ratings) (III / 3) ≙ Overvoltage category III / Pollution degree 3

Connection data

Total number of connection points 3

Total number of potentials 1

Number of levels 1

Connection 1

Connection technology CAGE CLAMP®

Actuation type Operating tool

Connectable conductor materials Copper

Solid conductor 0.2 … 10 mm² / 24 … 8 AWG

Fine-stranded conductor 0.2 … 10 mm² / 24 … 8 AWG

Physical data

Width 10 mm / 0.394 inch

Height 97.5 mm / 3.839 inch

Depth from upper edge of DIN-rail 35 mm / 1.378 inch

Mechanical data

Design horizontal type

Mounting type DIN-35 rail

Marking level Center marking

Material data

Note on material data Information on material data can be found here

Color blue

Insulation material Polyamide (PA66)

Flammability class per UL94 V0

Fire load 0.443MJ
