WAGO 2010-1302 3-conductor through terminal block; 10 mm²; suitable for Ex e II applications; side and center marking; for DIN-rail 35 x 15 and 35 x 7.5; 10,00 mm²; orange

WAGO 3-conductor ground terminal block; 1.5 mm²; center marking; for DIN-rail 35 x 15 and 35 x 7.5; CAGE CLAMP; 1,50 mm²; green-yellow 279-687

Product Name : WAGO 2010-1302 3-conductor through terminal block; 10 mm²; suitable for Ex e II applications; side and center marking; for DIN-rail 35 x 15 and 35 x 7.5; 10,00 mm²; orange

Directions

Ratings per IEC/EN

Ratings per IEC/EN 60947-7-1

Nominal voltage (III/3) 800V

Rated surge voltage (III/3) 8kV

Rated current 57A

Rated current 2 76A

Ratings per UL

Approvals per UL 1059

Rated voltage UL (Use Group B) 600V

Rated current UL (Use Group B) 65A

Rated voltage UL (Use Group C) 600V

Rated current UL (Use Group C) 65A

Ratings per CSA

Rated voltage CSA (Use Group B) 600V

Rated current CSA (Use Group B) 65A

Rated voltage CSA (Use Group C) 600V

Rated current CSA (Use Group C) 65A

Ex information

Ratings per ATEX: PTB 05 ATEX 1070 U / IECEx: PTB 06.0003U (Ex eb IIC Gb)

Rated voltage EN (Ex e II) 550V

Rated current (Ex e II) 50A

Ratings (note) See installation notes in section “Knowledge” and

Downloads – Documentation – Additional Information: Technical explanations
