Ratings per IEC/EN
Ratings per IEC/EN 60947-7-1
Nominal voltage (III/3) 800V
Rated surge voltage (III/3) 8kV
Rated current 57A
Rated current 2 76A
Ratings per UL
Approvals per UL 1059
Rated voltage UL (Use Group B) 600V
Rated current UL (Use Group B) 65A
Rated voltage UL (Use Group C) 600V
Rated current UL (Use Group C) 65A
Ratings per CSA
Rated voltage CSA (Use Group B) 600V
Rated current CSA (Use Group B) 65A
Rated voltage CSA (Use Group C) 600V
Rated current CSA (Use Group C) 65A
Ex information
Ratings per ATEX: PTB 05 ATEX 1070 U / IECEx: PTB 06.0003U (Ex eb IIC Gb)
Rated voltage EN (Ex e II) 550V
Rated current (Ex e II) 50A
Ratings (note) See installation notes in section “Knowledge” and
Downloads – Documentation – Additional Information: Technical explanations
