Product Name : WAGO 769-666/003-000 X-COM THT male header; 1.0 x 1.0 mm solder pin; angled; clamping collar; Pin spacing 5 mm; 6-pole; gray

Directions

Electrical data

Ratings per IEC/EN

Nominal voltage (III/3) 250V

Rated impulse voltage (III/3) 4kV

Rated voltage (III/2) 500V

Rated impulse voltage (III/2) 4kV

Rated current 32A

Connection data

Total number of potentials 6

Number of levels 1

Preceding contacts 0

Connection 1

Pole number 6

Physical data

Pin spacing 5 mm / 0.197 inch

Width 44.7 mm / 1.76 inch

Height from the surface 18.3 mm / 0.72 inch

Depth 22.2 mm / 0.874 inch

Mechanical data

Variable coding Yes

Mounting type Mounting flange

Plug-in connection

Contact type (pluggable connector) Male connector/plug

Connector (connection type) for PCB

Mismating protection No

Mating direction to the PCB 0°
